12x 4K PTZ Conference camera for business meeting
Product No.：TEVO-VL12U
Main Feature
USB3.0, HDMI, TYPE-C,Ethernet PTZ Camera with 12x optical zoom
8.29MP, 16:9
78.58° degree wide angle
Video Format YUY2/NV12/H.264/H.265/MJPG
Video Compression Format H.264,H.265,MJPG,YUY2,NV12
Network Protocol RTSP, RTMP, ONVIF, GB28181; Support VISCA Over IP
Support VISCA/Pelco-D/Pelco-P;Baud Rate:9600/4800/38400/2400
RS232 (input & output),RS485,TYPE-C(UVC1.1)
Compatible with any video conferencing software application and cloud services
- Fast Delievery
- Quality Assurance
- 24/7 Customer Service
Product Introduction
SZ Tenveo Video Technology Co., Ltd. is known as one of the leading manufacturers and suppliers in China, we now warmly welcome you to wholesale CE approved 12x 4k ptz conference camera for business meeting at low price from our factory. With the aid of advanced equipment and technology, we can assure you the high quality and good performance of our equipment. Contact us for pricelist and OEM&ODM service.
12x 4K PTZ Conference camera for business meeting
- Apply Sony IMX415 1/2.8" CMOS and TAMRON Lens offers a wide 78.58 degree FOV and support 12x optical zoom + 18x digital Zoom.The High SNR of CMOS sensor and 2D&3D Digital noise reduction supports working in 0.5 Lux Low Light well.
- As a PTZ camera,supports Pan/Tilt Rotation (±175°,-90°～+90°) .It has multiple ways of control, such as the included IR remote controller,VISCA/Pelco-D/Pelco-P;Baud Rate:9600/4800/38400/2400 via RS232 (input & output),RS485,TYPE-C(UVC1.1).
Is a Full HD professional live streaming camera and video conference camera,it can simultaneously output max 3840*2160P@30fps video from USB3.0 ,HDMI(4KP@30/25fps, HDMI and IP streaming(H.264,H.265,MJPG,YUY2,NV12). Support POE ( IEEE802.3af ) and RTSP, RTMP, ONVIF, GB28181; Support VISCA Over IP , and other technologies,ability to support advanced features for live streaming.
TENVEO Best Low vMix OBS VL 12X PTZ Broadcast Camera
FAQ
TEVO-VL12U USB3.0 / HDMI / IP PTZ CAMERA
| Item Name | Audio Conference System 12X PTZ Broadcast Camera | ||
| Model No. | TEVO-VL12U | ||
| Image Sensor | Sony IMX415 1/2.8" CMOS | ||
| Effective Pixels | 8.29MP, 16:9 | ||
| Lens | f=3.9-46.8mm | ||
| Aperture | F1.6 ~ F9.6 | ||
| Video Format | HDMI(4KP@30/25fps,1080P@60/50/30/25fps,720P@60/50/30/25fps) | ||
| USB3.0(3840*2160P@30fps,2560*1440P@30fps,1920*1080P@30fps,1280*720P@30fps,640*480P@30fps,320*240P@30fps | |||
| YUY2/NV12/H.264/H.265/MJPG) | |||
| Optical Zoom | 12x zoom | ||
| Horizontal angle | 70.82°(W)-6.48°(T) | SNR | >50dB |
| Vertial angle | 47.72°(W)-73.66°(T) | Focus | Auto / Manual |
| Diagonal angle | 78.58°(W)-7.42°(T) | Digital Noise Reduction | 2D & 3D Noise Reduction |
| Backlight Compensation | Support | Exposure | Auto / Manual |
| I / O Interface | |||
| Video Interfaces | HDMI, TYPE-C,Ethernet | ||
| Video Compression Format | H.264,H.265,MJPG,YUY2,NV12 | ||
| LAN | 10M/100M adaptive Ethernet port, Support POE IEEE802.3af | ||
| Network Protocol | RTSP, RTMP, ONVIF, GB28181; Support VISCA Over IP | ||
| Control Protocol | VISCA/Pelco-D/Pelco-P;Baud Rate:9600/4800/38400/2400 | ||
| Control Interface | RS232 (input & output),RS485,TYPE-C(UVC1.1) | ||
| PTZ Parameter | |||
| Pan/Tilt Rotation | ±175°,-90°～+90° | ||
| Pan Control Speed | 0.1 -80°/sec | ||
| Tilt Control Speed | 0.1-60°/sec | ||
| Preset Number | 255 presets by Pelco-D,32 presets by Pelco-P,7 presets by Visca (10 presets by remote controller) | ||
| General Parameter | |||
| Operation Systems | Windows 7, Windows 8.1, Windows 10,Windows 11; Android, Mac OS™ 10.10 or higher, Linux (Require to support UVC.) | ||
| Input Voltage | DC 12V | ||
| Input Current | 1.0A(Max.) | ||
| Power Consumption | 13W(Max.) | ||
| Store Temperature | -10℃～+60℃ | ||
| Store Humidity | 20%～90% | ||
| Working Temperature | -10℃～+50℃ | ||
| Working Humidity | 20%～80% | ||
| Dimension(W*H*D) | 171.6*192.6*171.6mm/260*217*197mm (before / after packing) | ||
| N.W. / G.W | 1.43kg/2.096kg | ||
| Accessory | 1xCamera; 1xUSB Cable;1xPower Adapter; 1xWall Mount; 1xManual | ||
| Mfg. Warranty | 3 Years Parts & Labor | ||
