Full Featured 4K 12X Optical Zoom NDI/POE/SDI/HDMI/USB PTZ Camera Video Conference Camera For Church/Live Streaming

Model No.

TEVO-UV612A-4K (NDI)

Image Sensor

Sony IMX415 1/2.8" CMOS

Effective Pixels

8.29MP, 16:9

Optical Zoom

12x zoom

Lens

f=3.42-40.02mm

Aperture

F1.88～F3.77

Horizontal Angle

80.56°(W)-7.89°(T)

Vertical Angle

49.61°(W)-4.46°(T)

Diagonal Angle

89.51°(W)-9.04°(T)

Video Format

HDMI(4KP@60/50/30/25fps,1080P@60/50/30/25fps,720P@60/50/30/25fps);

USB3.0(3840*2160P@30fps,2560*1440P@30fps,1920*1080P@30fps,1280*720P@30fps,640*480P@30fps,320*240P@30fps;

YUY2/NV12/H.264/H.265/MJPG

Video Encoding Format

H.264, H.265, MJPG, YUY2

Backlight Compensation

Support

SNR

>50dB

Focus

Auto / Manual

Digital Noise Reduction

2D & 3D Noise Reduction

Exposure

Auto / Manual

I / O Interface

Video Interfaces

HDMI, USB3.0, RJ45, SDI

Video Compression Format

H.264, H.265, MJPG, YUY2

LAN

10M/100M/1000M adaptive Ethernet port; Support POE IEEE802.3at

Network Protocol

NDI|HX2,RTSP, RTMP, ONVIF, GB28181; Support VISCA Over IP

Control Protocol

VISCA/Pelco-D/Pelco-P; Baud Rate: 9600/4800/38400/2400

Control Interface

RS232, RS485,USB3.0 TYPE-B(UVC1.1),RJ45

PTZ Parameter

Pan/Tilt Rotation

±175°, -90°～+90°

Pan Control Speed

0.1 -80°/sec

Tilt Control Speed

0.1 -60°/sec

Preset Number

User can set up to 255 presets (10 presets by IR remote)

General Parameter

Operation Systems

Windows 7, Windows 8.1, Windows 10, Windows 11; Android, Mac OS™ 10.10 or higher, Linux (Required to support UVC.)

Input Voltage

DC 12V

Input Current

2.0A (Max.)

Power Consumption

13W (Max.)

Store Temperature

-20°C to 60°C

Dimension (W*H*D)

171.6*192.6*171.6mm/ 260*217*197mm (before/ after packing)

N.W. / G.W.

1.35kg/ 2.05kg (Net/ Gross weight)
