1. 20x optical zoom, Sleek and intelligent design,Plug & Play USB Connectivity2. Crystal clear HD1080P image quality,Accurate,smooth and silent PTZ Movement3. Preset: 10 via IR remote setting (255 via PELCO-P/D/64 via VISCA)4. Interfaces: USB, SDI, HDMI5. 61°wide field of view with no video distortion(Pan:350°,Tilt: 61°(W)-3.64°(T))6. 1/2.8''SONY CMOS. High quality, 2.38 MEGA PIXEL (16:9) CMOS sensor7. Support ceiling mount, wall mount and tripod mount (Reverse mountable)
AI Tracking 20x zoom PTZ Video Conference Camera
Product No.:TEVO-NV20A
*20x optical zoom
*Sleek and intelligent design
*USB, HDMI, SDI,IP video outputs
*Crystal clear HD1080P image quality
*Accurate, smooth and silent PTZ Movement
*Preset: 9 via IR remote setting (256 via RS232)
*Superior quality with Full Glass Lens Material
*54.7 ° wide field of view with no video distortion
*1/3 inch high quality, 2.38MEGA PIXEL (16:9) CMOS sensor
*Support ceiling mount, wall mount and tripod mount (Reverse mountable)
*Support Visca, Pelco-P, and Pelco-D protocol, RS232/RS485 Camera Control
*Compatible with most leading video conferencing software and platform
- Fast Delievery
- Quality Assurance
- 24/7 Customer Service
Product Introduction
SZ Tenveo Video Technology Co., Ltd. is known as one of the leading manufacturers and suppliers in China, we now warmly welcome you to wholesale CE approved ai tracking 20x zoom ptz video conference camera at low price from our factory. With the aid of advanced equipment and technology, we can assure you the high quality and good performance of our equipment. Contact us for pricelist and OEM&ODM service.
Products Description
Main Features
Details Images
Product Paramenters
Product Packaging & Shipping
Company Profile
Product parameters:
Product No. | TEVO-NV20A |
Image Sensor | 1/3 inch HD Color CMOS |
Effective pixel | 2.38 mega pixel(16:9) |
Horizontal Resolution | 1080P60/50/30/25, 1080i60/50, 720P60/50 |
Signal standard | NTSC/PAL |
Zoom | 20x optical zoom |
Minimum luminance | 0.5Lux at F2.0 |
Focal length | F=5.5mm(wide)-110(tele) |
Horizontal Angle | Near-end 54.7°～Far-end 3.3° |
Gain control | Auto |
Focus | Auto |
White balance | Auto |
SNR ratio | ≥50dB |
Shutter speed | 8 to 1/10000s (auto) |
Preset position | IR remote control supports 9 presets, PELCO Protocol supports 256 presets |
Pan/Tilt movement range | Pan: ±175°(max speed 80°/S), Tilt: -35°~﹢55°(max speed 60°/S) |
Control terminal | USB,RS-232, RS485 |
Control Protocol | VISCA, PELCO-D, PELCO-P (RS-232, RS485) |
Video output | USB, HDMI, SDI, IP |
Video Compression Format | MJPG |
Noise Reduction | 2D/3D |
Work temperature | -10°C-~50°C |
Storage temperature | -20°C~60°C |
Baud rate | 38400/9600bps |
Decoder | Built-in |
Address set | 1~256 |
Installation | Support desktop, Tripod, Wall mount and Ceiling mount |
Power supply | DC12V/ 2A |
Power consumption | 12 W |
Net weight/Gross weight | 1.5kg/2.85g |
Dimension(LXWXH) | 260*175*180 mm /296*255*218mm (before / after packing) |
Accessories | DC 12V Power adaptor, IR remote control, Manual, USB2.0 cable, Ceiling brackets & screws. |
