Video Conferencing Installation
2.1 mega pixel
USB2.0 video output
1/2.9" SONY HD CMOS
HD1080P 20X optical zoom
Pan: 0-340° Tilt :0°~120°
RS-232, RS-485, IR remote control
- Fast Delievery
- Quality Assurance
- 24/7 Customer Service
Product Introduction
SZ Tenveo Video Technology Co., Ltd. is known as one of the leading manufacturers and suppliers in China, we now warmly welcome you to wholesale CE approved video conferencing installation at low price from our factory. With the aid of advanced equipment and technology, we can assure you the high quality and good performance of our equipment. Contact us for pricelist and OEM&ODM service.
Video Conferencing Installation TEVO-VHD202U
Tenveo video conferencing systems can be utilized to create events over the web where the video, the audio and the content are shared with distant participants. Known as “webinars”, these events are often used to share information given by a subject matter expert or to provide training.
TEVO-VHD202U Details:
Video Conferencing Installation Certifications:
Shipping and Payment Terms:
Product parameters:
Product No. | TEVO-VHD202U |
Image Sensor | 1/3" Exmor CMOS |
Effective pixel | 2.1 mega pixel（16：9） |
Horizontal Resolution | 1920x1080p 25/30fps / 1280x720p 25/30/50/60fps |
Signal standard | NTSC/P AL |
Zoom | 20x optical zoom |
Lens | F=4.7-94.0mm |
Horizontal Angle | Near-end 55.5°～Far-end 3.0° |
Gain control | Auto/manual |
Focus | Auto/manual |
SN ratio | ≥50dB |
Wide dynamic | D-WDR |
Shutter speed | 8 to 1/10000s,auto |
Character generator | Built-in OSD |
Preset position | IR remote control supports 9 presets, PELCO Protocol supports 256 presets |
Pan/Tilt movement range | Pan: 340°(max speed 80°/S), Tilt: 0°~120°((max speed 60°/S) |
Vertical rotation | 120° |
Pan/Tilt movement speed | 100°/s，80°/s |
Control terminal | RS-232，RS485 |
Control Protocol | VISCA，PELCO-D，PELCO-P（RS-232，RS485） |
Video output | USB2.0 |
Work temperature | -10°C-~50°C |
Storage temperature | -20°C~60°C |
Baud rate | 2400/4800/9600/19200bps |
Decoder | Built-in |
Address set | 1~256 |
Installation | Support desktop, wall mount and ceiling mounting |
Power supply | DC12 V/ 1A |
Power consumption | 12 W |
Net weight/Gross weight | 1.7kg/3.5kg (net/gross weight) |
Dimension(LXWXH) | 260*175*180 mm /296*255*238mm (before after packing) |
Accessories | DC/12V power adaptor, IR remote control, manual, RS232 cable, USB cable, Brackets & screws, Warranty card, Certificate of qualification |
Produce Information:
Video conferencing technology can be used as a production facility to produce content to be disseminated to employees and customers. The information produced can be archived for retrieval at a later date or streamed to individuals as needed. Save time with HR training by using Tenveo video conferencing equipment to present and record company policies. Create a special CEO message and send it out to all employees.
