NDI Live Streaming System AI Auto Tracking 12X Zoom NDI PTZ Camera With Joystick Controller BT Speaker For Events Live Broadcast
TEVO-VHD612A auto tracking ptz conference camera+M6B Bluetooth speakers +KB200PRO ip keyboard controller; is designed for small and medium sized conference room; the camera using the latest human detection AI algorithms to exhibit unparalleled tracking speed and accuracy; 1/2.8'' inches...
- Fast Delievery
- Quality Assurance
- 24/7 Customer Service
Product Introduction
SZ Tenveo Video Technology Co., Ltd. is known as one of the leading manufacturers and suppliers in China, we now warmly welcome you to wholesale CE approved ndi live streaming system ai auto tracking 12x zoom ndi ptz camera with joystick controller bt speaker for events live broadcast at low price from our factory. With the aid of advanced equipment and technology, we can assure you the high quality and good performance of our equipment. Contact us for pricelist and OEM&ODM service.
TEVO-VHD612A auto tracking ptz conference camera+M6B Bluetooth speakers +KB200PRO ip keyboard controller; is designed for small and medium sized conference room; the camera using the latest human detection AI algorithms to exhibit unparalleled tracking speed and accuracy; 1/2.8'' inches high-quality SONY CMOS sensor, support HDMI, USB, 3G-SDI and LAN interface.
TEVO-M6B Bluetooth microphone, with built-in 8 arrays of 360 degree omnidirectional microphones, can capture sound from all directions;
OEM Package, user manual, box lable, logo...etc;
Here are some picture refer:
|
Model No. |
VHD612A |
VHD620A |
VHD630A |
|
Camera |
|||
|
Sensor |
1/2.8'' |
||
|
Effective Pixels |
2.07MP |
||
|
Video Signals |
1080P60, 1080P59.94, 1080P50, 1080P30, 1080P29.97, 1080P25, 1080I60, 1080I59.94, 1080I50, 720P60, 720P59.94, 720P50 |
||
|
Zoom |
12x optical zoom |
20x optical zoom |
30x optical zoom |
|
Diagonal Angle |
77.5° ~ 7.53° |
69.5° ~ 3.86° |
69.5° ~ 2.63° |
|
Video Output |
USB 3.0, HDMI, RJ45, SDI |
||
|
Control Interface |
RS232, RS485, USB, NET |
||
|
White Balance |
Auto, Indoor, Outdoor, One Push, Manual, VAR |
||
|
Horizontal Rotation/Vertical Rotation |
350° (±175°) 0.1°/s～100°/s; 180° (±90°)0.1°/s～80°s |
||
|
Image Freeze/PoE/H & V Flip |
Support |
||
|
Number of Preset |
255 |
||
|
IPC Features |
|||
|
Video Encoding Format |
H.264/H.265/MJPG |
||
|
Video Stream |
Main Stream, Sub Stream |
||
|
Main Stream Resolution |
1920x1080, 1280x720, 1024x576 , 940x540,etc. |
||
|
Sub Stream Resolution |
1280x720, 1024x576, 720x480, 720x408,etc. |
||
|
Video Bit Rate |
32Kbps ~ 102400Kbps |
||
|
Bit Rate Type |
Variable Rate, Fixed Rate |
||
|
Frame Rate |
50Hz: 1fps ~ 50fps, 60Hz: 1fps ~ 60fps |
||
|
Network Protocol |
NDI |HX2,SRT,TCP/IP, HTTP, RTSP, RTMP, Onvif, DHCP, Multicast, etc. |
||
|
Bluetooth Microphone |
|||
|
Item Name |
M6B Bluetooth Speakerphone |
||
|
Bluetooth |
BT5.0 |
||
|
Battery |
8000mAH(Built-in lithium battery); Music time (up to 13 hours ); Fastest charge time: 3 hours; Regularly charge time up: 6 hours |
||
|
Connection Type |
USB/Bluetooth/Wireless/3.5mm Jack (Daisy-chain version has 2x3.5mm Jack) |
||
|
Meeting Room Size |
15-30㎡ |
||
|
Meeting With |
Up to 15 attendees |
||
|
Pickup Range |
6 meters (19.68 feet) |
||
|
Mics |
8 professional microphones in 4 directions |
||
|
KB200pro IP Keyboard Controller |
|||
|
CHIP |
HIS3536DV100 |
||
|
SYSTEM |
Linux |
||
|
Max equipment |
999 |
||
|
Decoding |
H.265, H.264 |
||
|
RESOLUTION |
MAX 1080P for 1 channel:1920*1080@30fps |
||
|
PROTOCOL |
VISCA over IP, NDI Control,Pelco-P,Pelco-D, Sony VISCA Compatible, ONVIF |
||
|
Camera Control |
Exposure Selection: YES ; White Balance: YES; Backlight Control: YES |
||
|
User Interfaces |
Display: LED; Speed Control: YES; Zoom Rocker: Yes; |
||
|
Joystick |
4D |
||
|
Output |
RS422(Reserved), RS232(Development port), RJ45 |
||
|
Accessories |
Knob, Silicone button |
||
|
Beep |
On/off |
||
|
Display |
TFT LCD 720*1280 |
||
|
Max camera control |
Max 255 with multiple protocols including NDI/IP |
||
