DVI Conference Camera
20X optical zoom
HD1080P 3.28 mega pixel
Pan: 0-340° Tilt ：+/-60°
VISCA,PELCO-D/P,RS232,RS485
3G-SDI,DVI,HDMI(DVI Transform)
- Fast Delievery
- Quality Assurance
- 24/7 Customer Service
Product Introduction
SZ Tenveo Video Technology Co., Ltd. is known as one of the leading manufacturers and suppliers in China, we now warmly welcome you to wholesale CE approved dvi conference camera at low price from our factory. With the aid of advanced equipment and technology, we can assure you the high quality and good performance of our equipment. Contact us for pricelist and OEM&ODM service.
DVI conference camera TEVO-VHD20N
DVI conference camera Appications:
DVI conference camera Shipping and payment terms:
DVI conference camera:
Product parameters:
Model No. | TEVO-VHD20S |
Image Sensor | 1/2.8 Exmor CMOS |
Effective pixel | 3.28 mega pixel（16：9） |
Video output | 1080P60/50/30/25 720P50/60 |
Signal standard | NTSC/PAL |
Zoom | 20x zoom |
Focus length | F=4.7-94.0mm |
Horizontal view angle | 59.5°(N)～3.3°(F) |
M.O.D | 1.0mm |
Minimum illumination | 0.25Lx（on） |
Gain control | Auto/manual |
Focus | Auto/manual |
SNR ratio | ≥50dB |
Shutter speed | 8 to1/10000s，Auto |
Preset position | Remote-controller support 9 presets；PELCO Control Protocol support 256 presets |
Pan/Tilt movement range | Pan: 340°(Max Speed 80°/S)； Tilt: 0°～120°(Max Speed 60°/S) |
Pan/Tilt movement speed | 100°/S；80°/S |
Control terminal | RS-232，RS485，RS-422 |
Control Protocol | VISCA，PELCO-D，PELCO-P（RS-232，RS485） |
Video output | 3G-SDI,DVI,HDMI(DVI Transform) |
Work Temperature | -10°～50° |
Work Humidity | -20°～60° |
Baud rate | 2400/4800/9600/19200bps |
Decoder | Built-in |
Address Settings | 1~256 |
Installation | Desktop ,Ceiling ,mounting installation |
Power supply | DC12V/2A |
Power | 12W |
Weight | 1.7kg/3.5kg |
Size | 260*175*180 mm /296*255*238mm (before after packing) |
Accessories | DC 12Vpower adaptor，IR remote control，celling Brackets，manual，RS-232Ccable，YPBPR cable |
